• Complies with the IEEE 802.3, IEEE 802.3u, and IEEE 802.3ab Ethernet standards
• 32-port RJ45
• 16-port 10/100/1000Mbps data input
• 16-port 10/100/1000Mbps data + power output
• One 10/100/1000BASE-T management port

Power over Ethernet:

• Ultra Power over Ethernet end-span/mid-span PSE
• Up to 60 watts of power on 4-pair UTP
• Backward compatible with IEEE 802.3at/af PD devices
• 52V DC, 60-watt PoE power output at maximum on each port
• 600-watt PoE budget
• Auto-detection of IEEE 802.3at/af PoE equipment and devices to avoid possible damage by incorrect installation
• Circuit protection prevents power interference between ports
• Remote power feeding up to 100m

PoE Management:

• Per port PoE power schedule
• PoE function enable/disable
• Per port PoE function enable/disable
• PoE port power feeding priority
• PD classification detection
• Over temperature protection
• PD alive check
• PoE schedule

Management:

• Web interface for remote management
• Supports Network Time Protocol (NTP)
• Firmware upgrade through web interface
• PLANET Smart Discovery utility automatically finds PLANET devices on the network
• SNMP trap for alarm notification of events
• System log/remote syslog

Hardware:

• 19-inch rack mountable; 1U height
• Reset button for resetting to default setting and system reboot
• LED indicators for PoE ready and PoE activity
• LED indicators for power alert and fan alert
• LED indicators for PoE power usage status (watts)
• FCC Part 15 Class A, CE.
