The luminaire housing consists of a die-cast aluminum unit designed to accommodate LED SMD technology and a black heat sink with ribbed construction for passive heat dissipation. It features a one-axis suspended white cover and mounting ring with a satin-finished PC cover. The uniform symmetrical light distribution occurs at a beam angle of 95°. The adjustable product version allows for an angle of ±15°. The wiring between the luminaire and the ballast is approximately 25 cm long and equipped with a coded snap-in hollow plug and socket connection.

Ballast features: It includes an electronic ballast that can be dimmed on the primary side (230V/50Hz) using dimmer inserts for electronic transformers (phase-cut). It has an internal 2-pole screw terminal and a screwable strain relief for the cover.

Mounting type: Convenient tool-free installation using metal retaining clips. A hole size of Ø 68 ± 2 mm is required for ceiling panel thicknesses up to 20 mm.
