Aircraft piston compressor 221 OF E Handy Silence

• Small portable compressor with compact design
• Very smooth operation and therefore very quiet
• Oil-free piston compressor: no oil change necessary and no oil in the condensate for optimum work quality
• Compressed air regulator for infinitely variable adjustment of the desired working pressure
• High-quality pressure switch
• Electric motor equipped with motor protection switch
• Fully automatic on/off operation
• One pressure gauge each for displaying the tank and working pressure
• Powder-coated compressed air tank
• Vibration-damping suction cups

Technical data

General information
Air outlet: ¼"

Dimensions and weights
Length (product) approx.: 370mm
Width/depth (product) approx.: 270mm
Height (product) approx.: 530mm
Weight (net) approx.: 16kg

Electrical data
Supply voltage: 230V
Mains frequency: 50Hz
Output power: 1.0kW
Input power: 1.1kW
Drive motor power: 0.75kW
Drive motor duty cycle: 70%

Noise emission
Sound power level Lp: 61dB(A)

Compressor
Compressor system: WDS
Oil-free / oil-lubricated: Oil-free
Suction capacity approx.: 200l/min
Filling capacity approx.: 90l/min
Explanation Filling capacity: at 6 bar working pressure
Number of cylinders: 2
Number of compression stages: 1
Compressor speed: 2850min¯¹
Piston stroke: 11.2mm
Piston diameter: 63.7mm

Compressed air reservoir
Maximum pressure: 8bar
Tank capacity: 6 litres
Tank upright / horizontal: Horizontal
Tank surface: powder-coated.
