Kaiser Internal Insulation Box 1159-90

Manufacturer: Kaiser
Designation: Internal Insulation Box
Type: 1159-90
Mounting Type: Flush-mounted
Shape: Rectangular
Design: Device Connection Box
Version: Single
With Rotatable Ring: No
Couplable: Yes
Filling: None
Diameter: 60 mm
Length: 75 mm
Width: 77.1 mm
Depth: 90 mm
Internal Depth: 47 mm
For Number of Device Inserts: 1
Device Attachment: Screws
With Screws: Yes
Housing Entry through Breakout Opening: No
Housing Entry through Seal Membrane: No
Housing Entry through Pipe Socket: No
Housing Entry through Step Membrane: No
Suitable for Cable Diameter: 11.5 mm
Pipe Locking: No
Pipe Locking Optional: No
Rear Entry: No
Number of Entries: 4
Material: Plastic
Halogen-free: Yes
Surface Protection: Untreated
Color: Black
Protection Class (IP): IP20
Cover Version: None
Transparent Cover: No
Cover Attachment: Screwed
Seal-able: No
Function Maintenance: None
With Shielding: No
Air-tight: No
Max. Conductor Cross-section: 2.5 mm²
Terminal Position Fixed: No
Light Hook Attachment: No
Socket: None
Special Application: Other
With Partition Wall: No

Kaiser Internal Insulation Box 1159-90: Additional Details
Internal insulation box for insulation thicknesses of 30 - 100 mm (1159-90). Device connection box for electrical installations in internal insulation systems. For permanently secure and thermal bridge-free attachment of switches, sockets, and other devices in internally insulated exterior walls. For an optimal indoor climate with proven protection against moisture damage. Applicable in many internal insulation systems. Device Screws: 2 | Depth: 90 mm.
