Multimeter
EUR93,38
Benning Double pole voltage tester DU
CAT III 1000V, CAT IV 600V, Handheld multimeter
Best selling Multimeters from Benning
This page always stays fresh and updates automatically.
1. Benning Double pole voltage tester DU
The DUSPOL digital is a digital True RMS voltage and continuity tester with resistance and frequency range. The voltage tester is suitable for electrical engineering, industry, maintenance, service (troubleshooting), as well as photovoltaic and wind power systems.
2. Benning Wallbox tester
Benning EV 3-3 is a wallbox tester and measurement adapter that allows for easy and quick functional testing as well as troubleshooting of wallboxes. When used with the installation testing devices BENNING IT 200 or BENNING IT 130, it enables safety and functional testing of AC charging stations (wallboxes) for electric vehicles according to DIN VDE 0100-600 and DIN VDE 0105-100. It is compatible with 1- and 3-phase charging stations (EVSE) of charging mode 3 with Type 2 connectors.
The device facilitates simple functional testing of the wallbox and the connection of the installation device to the charging station. It simulates different current load capacities (codings) of 13 A, 20 A, 32 A, and 62 A for the charging cables. It also simulates various vehicle states: A (not connected), B (connected, not ready), C (charging without ventilation), D (charging with ventilation), and E (error, short circuit between CP-PE / PE disconnected).
Additionally, it analyzes the CP and PP signals (vehicle status, signal voltage, frequency, duty cycle). It measures voltage and phase rotation, with separate phase indicators (L1/L2/L3) indicated by three LEDs as soon as the charging station provides power. The device triggers the 30 mA AC and 6 mA DC residual current device with time measurement. It features a test socket and 4 mm sockets (L1/L2/L3/N/PE) for easy connection to the installation testing device. The EVSE locking system is checked from status B (release of the charging cable is blocked). It has a measurement category of CAT II 300 V and includes a protective case.
3. Benning Socket tester
Quick and easy testing of protective contact sockets for correct connections. Wiring errors such as missing PE, N, and L conductors, as well as the swapping of L and PE conductors, are clearly indicated by three LEDs. The active PE test with a touch electrode and LCD display warns of the presence of a dangerous touch voltage over 50 V at the protective conductor connection (PE). A test button triggers the 30 mA RCD circuit breaker. Clear indication via LEDs and LCD display. An easy-to-understand status table informs about the correct connection (OK, green) and the type of error present (red) in the protective contact socket. Measurement category CAT III 300 V. Additional technical features: Display: LCD/LEDs.
What our customers think
Pro
- Highly recommended
- Simple operation
- Easy handling
4. Benning IT 130
Multifunctional installation tester for safety testing of electrical installations in accordance with IEC 60364 and EN 50110. Testing of residual current circuit breakers (RCD) type B/B+ (universal) and types AC, A, F (mixed frequencies)
Measured value memory for four levels (object/block/fuse/measuring point) for up to 1800 measurements. Bidirectional USB/RS 232 interface, including BENNING PC-Win IT 130 software, Commander test pen with TEST and MEM button and powerful LED measuring point illumination.
5. Benning 044104
The Benning IT 115 is a state-of-the-art handheld multimeter specifically designed for testing electrical installations. It meets the requirements of DIN VDE 0100-600, IEC 60364-6, and DIN VDE 0105-100 as well as EN 50110. With its graphical display and backlighting, it offers a user-friendly interface that is easily readable even in low light conditions. The device supports a wide range of measurements, including insulation resistance, low resistance measurement, and earth measurement, and is capable of delivering precise results across a broad voltage range. The integrated help function with connection diagram simplifies usage and ensures efficient operation. The IT 115 is an indispensable tool for professionals working in electrical installation who demand the highest standards of measurement accuracy.
- True RMS measurement for precise results
- Graphic display with backlighting and help function
- Extensive testing options for RCD/ELCB protection switches
- Earth measurement using the 3-wire method
- Calibration to factory standard with certificate.
6. Benning ST 725
Safety testing of electrical devices/work equipment according to VDE 0701-0702, DGUV regulation 3 (BGV A3) and BetrSichV. Mains operation enables the testing of devices with power supply units, such as electronically controlled devices/ tools, PCs, copiers and washing machines under functional conditions. Protective conductor resistance with ≥ 200 mA pulse test current - necessary for oxidised contacts. Insulation resistance with 250 V and 500 V test voltage. Protective conductor / contact current in differential method / direct measurement in mains operation and in substitute leakage current method in battery operation. Active measurement of protective conductor current of 3-phase devices under functional condition with optional measuring adapter. Testing of permanently installed and mobile 30 mA RCD/PRCD circuit breakers with measurement of the tripping time. Voltage measurement at external earthed socket.
7. Benning Control instrument ST710, 050308
The Benning ST 710 appliance tester is a sophisticated tester specially designed for testing electrical appliances in accordance with VDE standards 0701 and 0702. This digital multimeter offers a variety of functions that enable professionals to efficiently check the safety and function of electrical devices. With a robust construction and user-friendly design, the ST 710 is ideal for use in various environments, whether in industry, trade or the service sector. The appliance tester is battery-operated and allows flexible use without restrictions due to power sources. The graphic display ensures a clear and precise reading of the measured values, while the various measuring ranges enable comprehensive testing of insulation resistances and protective conductor resistances. The ST 710 is therefore an indispensable tool for anyone who regularly tests electrical devices and needs to ensure that they comply with the applicable safety standards.
8. Benning Hand Multimeter digital MM 6-2
Robust, compact, and precise True RMS digital multimeter with multifunctional measurement ranges for various applications. The True RMS measurement method allows for use in demanding measurement tasks and precise troubleshooting in electrical systems. The highest measurement category CAT IV 600 V provides maximum protection against overvoltage. The measurement functions are designed to meet the diverse requirements of electrical professionals in trades, industry, and service, as well as heating and air conditioning technicians. A rubber protective case safeguards the multimeter during rough industrial use. The integrated magnet in the rubber case allows the multimeter to be hung up. The AutoV function automatically detects DC or AC voltage. The low input impedance suppresses ghost voltages. Continuity testing is indicated by a loud buzzer and an additional red LED in noisy environments. The integrated voltage sensor is used for non-contact testing of phase voltage and locating cable breaks in lines. This multifunctional multimeter is complemented by features such as LCD lighting, HOLD, PEAK, and REL. The package includes a high-quality protective case and the rubber holster, among other items.
Multimeter
−5%
EUR195,12 was EUR205,62
Benning Hand Multimeter digital MM 6-2
CAT III 1000V, CAT IV 600V, Handheld multimeter
9. Benning Hand-held multimeter digital MM 5-2
Innovative digital multimeter series with true RMS measurement method and integrated voltage sensor.
Industrial environments demand true RMS measuring instruments.
Non-linear loads, such as those created by variable speed motor drives, frequency converters, or power supplies for office equipment and LED lights, generate reactive power in the network. This results in multimeters and clamp meters using the average value measurement method (RMS) displaying less accurate readings.
In many cases, especially in industrial environments, the use of modern true RMS measuring instruments is necessary. The true RMS measurement method accurately displays the actual effective value of an alternating current, regardless of whether the waveform of the current is sinusoidal or distorted.
Multimeter
−10%
EUR176,17 was EUR196,46
Benning Hand-held multimeter digital MM 5-2
CAT III 600V, CAT IV 300V, Handheld multimeter
10. Benning Current clamp, hand multimeter di
Robust and compact current clamp for safe AC measurement up to 400 A/AC. Additionally, AC/DC voltages, resistances, continuity, and diode tests can be performed. The readings are displayed digitally on an LCD screen. A slide switch allows for the selection of three measurement ranges, enabling the measurement of household and industrial currents.
Multimeter
EUR196,65
Benning Current clamp, hand multimeter di
CAT III 1000V, CAT IV 600V, Handheld multimeter
