Technical Specifications for Zenbook S 16
Article Number: 90NB13M1-M00LE0
EAN: 4711387769041
Color: Zumaia Gray (2I)
Display:
• 16:10 OLED Panel
• 16.0" (40.6 cm)
• WQXGA+ (2880 px x 1800 px)
Processor: AMD Ryzen™ AI 9 HX 370 (36 MB Cache, up to 5.1 GHz)
AMD Ryzen™ AI up to 50 TOPs
Graphics: AMD Radeon™ 890M
Memory: 32 GB LPDDR5X (32 GB LPDDR5X Onboard)
Storage: 1 TB PCIe Gen4 M.2 SSD
Wi-Fi: Wi-Fi 7 (802.11be Tri-band) 2x2
Bluetooth: Bluetooth 5.4
Keyboard: Backlit Chiclet Keyboard
Webcam: IR FHD Webcam for Windows Hello
Audio:
• Built-in array microphone
• Built-in speaker
• Smart Amp Technology
Power Supply:
• Battery: 78 WHrs, 2S2P, 4-cell Li-ion
• Power Adapter: 20V 3.25A (65W), Connector Type: TYPE-C
Operating System: Windows 11 Home
Additional Software: Microsoft 365 (30-day trial)
Accessories: Sleeve
Manufacturer: ASUS
Weight: 1.50 kg
Dimensions (Width x Height x Depth): 35.36 cm x 1.19 ~ 1.29 cm x 24.30 cm
Welcome to the Future: The ASUS Zenbook S 16
The ASUS Zenbook S 16 combines exceptional lightness and ultimate thinness with powerful AI features and a stunning 2.8K OLED Lumina display. With its dedicated copilot key, a sleek Ceraluminum™ chassis, and comprehensive connectivity, the Zenbook S 16 sets new standards for premium notebooks. Immerse yourself in a world of brilliance, performance, and comfort – ready to elevate productivity to a new level.
Processor family | Ryzen AI 9 3rd Gen |
Memory | 32 GB |
SSD capacity | 1000 GB |
Operating System Version | Windows 11 Home |
Image resolution | 2880 x 1800 pixels |
Keyboard layout | Germany |
Graphics card model | Radeon 890M |
Item number | 49264299 |
Manufacturer | ASUS |
Category | Notebooks |
Manufacturer no. | 90NB13M1-M00LE0 |
Release date | 11/9/2024 |
Colour | Grey |
Exact colour description | Zumaia grey |
Notebook type | Multimedia laptop |
Model number | UM5606WA-RK333W |
Processor family | Ryzen AI 9 3rd Gen |
Processor type | AMD Ryzen AI 9 HX 370 |
Clock frequency | 2 GHz |
Max. turbo clock rate | 5.10 GHz |
Max. TDP | 54 W |
Number of processor cores | 12 -Core |
Number of threads | 24 |
Cache | 24 MB |
Chipset | AMD SoC |
Memory | 32 GB |
Memory configuration | 1 x 32GB |
Onboard memory | 32 GB |
Max. supported memory | 32 GB |
Memory type | LPDDR5X-RAM |
Storage clock frequency | 3200 MHz |
Graphics hardware | Integrated graphics |
Material group | Metal |
Material | Ceraluminium™ |
Graphics chip (GPU) | AMD Radeon |
Graphics card model | Radeon 890M |
Graphics card model | Radeon 890M |
Display resolution | WQXGA+ |
Image resolution | 2880 x 1800 pixels |
Refresh rate | 120 Hz |
Aspect ratio | 16:10 |
Display size (inches) | 16" |
Screen surface | Anti-glare |
Screen technology | OLED |
Panel technology | OLED |
Brightness | 400 cd/m² |
Disk type | SSD |
Total capacity | 1000 GB |
SSD capacity | 1000 GB |
Optical drive type | No drive |
Memory card type | SD |
USB ports | USB-A, USB-C |
Exact USB ports | USB-A 3.2 Gen 2 (2x), USB-C 4 (2x) |
Video connections | HDMI (1x) |
Audio Connections | Jack 3.5mm (1x) |
HDMI version | 2.1 |
Operating system | Windows |
Operating System Version | Windows 11 Home |
Language | German |
Operating system architecture | 64-bit |
Notebook speaker type | Smart Amplifier Technology |
Number of speakers | 2 x |
Audio channel | Stereo |
Front camera resolution | 2 Mpx |
Max. Video resolution front camera | 1920 x 1080 pixels |
Safety | Trusted Platform Module, Windows Hello Face sign-in |
Password protection Type | Switch on |
Wireless transmission | Bluetooth, Wi-Fi |
Bluetooth version | 5.4 |
Wi-Fi standard | Wi-Fi 7 / 802.11be |
Battery type | Li-ion |
Number of cells | 4 Cells |
Power capacity | 78 Wh |
Power supply unit strength | 65 W |
USB Type C Power supply | 65 W |
Keyboard layout | Germany |
Input device | Keyboard backlight, Touchpad |
Country of origin | China |
Manufacturer commitment | RE100, SBTi |
Manufacturer compensation | According to RE100, the manufacturer ASUS fully compensates for its energy consumption, leading to a reduction in emissions. |
CO₂-Emission | |
Climate contribution |
Scope of delivery | ASUS ZenBook S 16 AI R9 HX 370 32GB 1TB UM5606WA-RK333W W11H |
Height | 1.29 cm |
Depth | 24.30 cm |
Width | 35.36 cm |
Weight | 1.50 kg |
Length | 49 cm |
Width | 32 cm |
Height | 12 cm |
Weight | 3.57 kg |
Product Safety |
How often does a product of this brand in the «Notebooks» category have a defect within the first 24 months?
Source: GalaxusHow many working days on average does it take to process a warranty claim from when it arrives at the service centre until it’s back with the customer?
Source: GalaxusHow often is a product of this brand in the «Notebooks» category returned?
Source: Galaxus
The Zenbook S16 completed the tests in no time at all, the image quality measurements revealed an AAA display and it offered a very long battery life. It also has fast Wi-Fi 7, a card reader and plenty of SSD and RAM. It's a shame that the RAM can't be swapped out. But that's a side note...
